3CX Webhook

A plugin for PBX 3CX that allows you to generate webhook events. The plugin allows you to implement integration with many CRM or Service Desk systems

3CX webhook

    Ringing

    The event is generated when a call is received in the PBX

    Queue

    It generates events of the call passing through the PBX

    3CX MP3 Records

    Get a URL to download an mp3 records from your server

    Picking up the phone

    Employee response event to an incoming call

    Missed calls

    The event of a missed call by an employee or from a queue

    Outgoing

    Employee outgoing call event

    3CX WebHook Generator

    13:23:50
    Incoming call DID 420223003090 IVR 800
    event=ringing&callerid=420774852640&user=800&usertype=other&did=DID-420223003090&id=220726165956_2-0
    13:23:50
    13:24:01
    Queue 802
    event=ringing&callerid=420774852640&user=802&usertype=queue&did=DID-420223003090&id=220726170922_4-0
    13:24:01
    13:24:09
    Agent 102 receives a call
    event=ringing&callerid=420774852640&user=102&usertype=ext&did=DID-420223003090&id=220726170922_4-0
    13:24:09
    13:24:13
    Agent 102 picked up the phone
    event=hangupincoming&callerid=420774852640&user=102&did=DID-420223003090&trtype=NotDef&id=220726170922_4-1
    13:24:13
    13:27:37
    Call ends
    event=incoming&callerid=420774852640&user=102&finishtype=Ok&transfer=False&did=DID-420223003090&title=DID-420223003090:Success call 420774852640(3:24)&id=220726170922_4-1
    13:27:37
    13:27:39
    Few moments later
    {
    "FILES": ["https://fqdn.my3cx.eu:5001/webapi/recording/220726170922_4-1-1.mp3" ]
    }
    13:27:39

    Pricing 3CX Webhook

    Pricing is based on the number of concurrent calls required (SC). This includes internal and external calls 3CX.

    • Webhook Generator 4 SC
      $ 179
    • Webhook Generator 8 SC
      $ 239
    • Webhook Generator 16 SC
      $ 359
    • Webhook Generator 24 SC
      $ 479
    • Webhook Generator 32 SC
      $ 599
    • Webhook Generator 48 SC
      $ 719
    • Webhook Generator 64 SC
      $ 959
    • Webhook Generator 96 SC
      $ 1 199
    • Webhook Generator 128 SC
      $ 1 679
    • Webhook Generator 192 SC
      $ 2 159
    • Webhook Generator 256 SC
      $ 2 399
    • Webhook Generator 512 SC
      $ 3 599
    • Webhook Generator 1024 SC
      $ 4 799
    • The price doesn’t include any taxes or VAT
    • Annual licenses

    Technical features

    The “webhooks” module is used to integrate 3CX with third-party CRM systems. It is written in C #, implemented as a service and connects to 3CX at the time of start. As a result, the module continuously monitors the low-level telephone exchange activity and on this basis of monitoring generates a high-level events occur:

    • ringing
    • call start
    • call end

    3CX Webhook generator sends  at the moment of each of the events https-request (webhook) on the address specified in the .ini file with certain data about the call.

    Note: if an extension’s phone range, and then stopped ringing, but the call did not end (went to another extension), then there is no such event (the extension’s phone stopped ringing, but the call did not end).

    Description of the data that is transmitted via webhooks when events occur

    Сall initialization

    • event = ringing/dialing
    • callerid = Caller ID
    • did = external number the call was received from (incoming DID rule)
    • user = user extension
    • usertype = ext/queue/other
    • id = unique call id (string value). If a call has come to the queue and the phone is sequentially or simultaneously ringing for several managers, then they will all have the same id.

    Call started

    • event = hangupincoming / hangupoutgoing (Incoming or outgoing call)
    • callerid = External number participating in the conversationExtension
    • user =participating in the conversation
    • did = If the call is incoming, then the external number that received the call (DID- rule)
    • trtype = NotDef / Blind / Accomp (How the call was received: 1) a regular call, 2) a call received through a blind transfer, 3) a call received through an accompanying transfer)
    • Id = Unique call id (string value) The

    Call ended

    • event = incoming / outgoing
    • callerid = External number
    • user = Internal number. If the call is missed, and it ended at the queue level, then this will be the queue extension
    • finishtype = Ok / Missed (How the call ended: successful (there was a conversation) or unsuccessful (i.e. when an outgoing call was called, but the other end did not picked up the phone, and when the call came in, no one answered the call on the 3CX side))
    • transfer = false / true (Did the call end completely, or went through the transfer to another extension)
    • title = As a phrase, detailed information about the call, which, in addition to the above includes: a) the name of the DID rule for an incoming call; b) if the call ended at the queue level, was a callback ordered; c) call duration
    • id = Unique call id (string value) The

    call ID is formed as follows:

    [date time]_[unique call number within the current 3CX session]-[call link number]

    Example ID: 210701165649_698-2

    Date and time correspond to the moment when the call arrived at the 3CX. A call link is a sequence number of a call in a single chain of transfers. When a call has just arrived at the PBX, and no one has answered it yet, the call link is equal to 0. As soon as someone answers, it is equal to 1. For each subsequent transfer, the call link is increased by 1. All calls in a single transfer chain have a date time and a unique number within the current session are the same. Such calls differ only in the link number.

    Example:

    https://webhook.site/?event=ringing&callerid=420774852629&user=106&usertype=other&did=PragueDID&id=211230100614_665-0
    https://webhook.site/?callerid=420774852629&event=hangupincoming&user=106&did=PragueDID&trtype=NotDef&id=220106205945_755-1





    After the complete end of the call (when the external subscriber hangs up), a recording of the conversation appears in 3CX, or several recordings of conversations that correspond to the entire chain of transfers, if any. Recordings of conversations appear with a slight delay: from a few milliseconds to 1-2 seconds after hanging up. As soon as this happens, the “webhooks” module converts the wav-file (s) with the recording (recordings) into mp3-format and places them in a separate folder, from which it is possible to download recordings via an https-link. The link to download the files is sent via the corresponding POST request. Thus, a webhook with information about the end of the call and a webhook with a link to the conversation file are different, separate webhooks.

    In a POST request, in the general case, several links can be sent to download a conversation recording. The fact is that in 3CX one conversation can correspond to several sound files. This happens if they spoke through a mobile application, and during the conversation, the connection was lost for a short time. In this case, each short-term disconnection is the beginning of a new record file.

    In addition to the link to the conversation record, the POST request contains a call id, by which it can be identified with the call start / end events. Optionally (via an ini file) in the POST request, you can enable the transfer of complete information about the ended call. In this case, the POST request will contain the same information (besides the link to download the record) as the call termination event.

    Records of conversations in mp3 format are stored in a separate package for the required number of days (the corresponding parameter is set in the ini-file of the service). At night, records that have expired are automatically deleted by the service.

    Example:

    {"FILES":["https://3CXFQDN:5001/webapi/recording/211230102738_669-1-1.mp3"]}

    1. Create a separate database on the same 3CX instance (dbname with dbpassword)

    2. Create table

    — Table: public.operator_state_history

    — DROP TABLE IF EXISTS public.operator_state_history;

    CREATE TABLE IF NOT EXISTS public.operator_state_history
    (
    date timestamp with time zone,
    old_values text COLLATE pg_catalog.”default”,
    new_values text COLLATE pg_catalog.”default”,
    ext text COLLATE pg_catalog.”default”
    )
    WITH (
    OIDS = FALSE
    )
    TABLESPACE pg_default;

    ALTER TABLE IF EXISTS public.operator_state_history
    OWNER to phonesystem;

    3. Specify the following in the TCXWebAPI.ini

    DBS_NAME = dbname
    DBS_PORT = 5480
    DBS_LOGIN = phonesystem
    DBS_PASSWORD =dbpassword
    DBS_TABLE = public.operator_state_history

    4. Select user history

    SELECT date, old_values, new_values, ext
    FROM public.operator_state_history
